P8Z68-V LE. Your dream Z68 motherboard, with full support for faster video transcoding and universal switchable graphics.
- Dual Intelligent Processors - TPU & EPU
- UEFI BIOS (EZ Mode) Flexible & Easy BIOS Interface
- GPU Boost. Go to the Limit with iGPU Level Up!
- LucidLogix® Virtu (Universal Switchable Graphics) Auto Switching between Integrated Graphics and NVIDIA/AMD Cards
- Intel® Smart Response Technology. SSD Speed with HDD Capacity
- Quad USB 3.0/SATA 6Gb/s Support - Double Access, Double Convenience
Specifications:
- CPU: Intel® Socket 1155 for 2nd Generation Core™ i7/Core™ i5/Core™ i3 Processors. Supports Intel® 32 nm CPU
- Chipset: Intel® Z68
- Memory: 4 x DIMM, Max. 32GB, DDR3 2200(O.C.)/2133(O.C.)/1866(O.C.)/1600/1333/1066 MHz Non-ECC, Un-buffered Memory. Dual Channel Memory Architecture
- Graphic:
Integrated Graphics Processor
Multi-VGA output support : HDMI/DVI/RGB ports
• Supports HDMI with max. resolution 1920 x 1200 @ 60 Hz
• Supports DVI with max. resolution 1920 x 1200 @ 60 Hz
• Supports RGB with max. resolution 2048 x 1536 @ 75 Hz
Maximum shared memory of 1748 MB
- Multi-GPU Support:
• Supports AMD Quad-GPU CrossFireX™ Technology
• Supports LucidLogix® Virtu™ Technology
- Expansion Slots:
• 1 x PCIe 2.0 x16 (blue) *1
• 1 x PCIe 2.0 x16 (x4 mode, black) *1
• 2 x PCIe 2.0 x1
• 3 x PCI
- Storage:
Intel® Z68 chipset :
• 2 x SATA 6Gb/s port(s), gray
• 4 x SATA 3Gb/s port(s), blue
• Support Raid 0, 1, 5, 10
• Support Intel® Smart Response Technology on 2nd generation Intel® Core™ processor family
- LAN: Realtek® 8111E , 1 x Gigabit LAN Controller(s)
- Form Factor: ATX Form Factor 12 inch x 9 inch ( 30.5 cm x 22.9 cm )
