Specifications:
- CPU: AMD Socket AM3 ;Phenom™II /Athlon™II /Sempron™ 100 Series Processors, AMD 140W CPU Support, AMD Cool \'n\' Quiet™ Technology, Supports 45nm CPU
- Chipset: AMD 890FX/SB850
- System Bus: Up to 5200 MT/s ; HyperTransport™ 3.0
- Memory: 4 x DIMM, Max. 16 GB, DDR3 2000(O.C.)/1800(O.C.)/1600(O.C.)/1333/1066 ECC,Non-ECC,Un-buffered Memory, Dual Channel memory architecture.
- Expansion Slots:
• 3 x PCIe 2.0 x16 (dual @ x16, triple @x16 x8 x8)
• 1 x PCIe 2.0 x4
• 2 x PCI 2.2
- Multi-GPU Support: Support ATI CrossFire™X Technology graphics cards
- Storage:
SB850 Chipset
• 6 xSATA 6.0 Gb/s ports Support RAID 0,1,5,10
JMicron® JMB363 PATA and SATA controller
• 1 xSATA 3Gb/s port (Black)
• 1 xExternal power SATA 3Gb/s port on rear (SATA On-the-Go)
* Due to the Windows XP/ Vista limitation, the RAID array with the total capacity over 2TB cannot be set as a boot disk. A RAID array over 2TB can only be set as a data disk only.
- LAN: Marvell 8059 Gigabit LAN controller
- Audio: SupremeFX X-Fi built-in 8-Channel High Definition Audio CODEC
- IEEE 1394: 2 x 1394a port(s) (1 port at back I/O, 1 port onboard)
- USB:
• NEC® USB 3.0 controller
• 2 x USB 3.0/2.0 ports (at back I/O)
• 12 x USB 2.0 ports (5 ports at mid-board, 7 ports at back I/O, 1 port at back I/O is also for ROG connect)
- Form Factor: ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x24.5 cm )
